Description
- High-capacity cutting: cuts up to 7 bands simultaneously, up to 65 m/min (70 yards/min) per band
- Wide fabric range: processes tubular material from 14″–43″, with prefeed device supporting up to 92cm (36″) fabric width
- New Heavy Duty Cutting Head Assembly: allows horizontal or vertical orientation for flexible setup
- Fast, tool-free changeovers: pneumatic knife engagement/disengagement and quick-change knife holders
- Ergonomic, efficient operation: pneumatic roll lifter with quick-removable roll-up bar and adjustable touch control panel
Euro Collarette 450-XF Band Cutting Machine Brochure.
Technical Data
- Fabric width: 35-110 cm (14-43”)
- Prefeed Device: up to 92 cm (36”)
- Binding width: 16-300 mm (5/8-12”)
- Number of Bands: Up to 7 bands (with standard 6 knives)
- Cutting capacity: 7 X 0-65 m/min (~70 yards/min)
- Cutting system: Primary cut is a shear cut; secondary cut is a crush cut.
Machine dimensions
Floor space: 180 x 180 cm ( 6 x 6 ft)
